AnyScan® TRIO SPECT/CT/PET

An integrated triple-detector SPECT/CT and PET/CT system in a single-room installation with cost optimized return of investment and operation

Make your perfect choice with this unique integrated PET/CT and SPECT/CT system, featuring a uniform triple-detector AnyScan® TRIO design and seamless workflow within a single-room installation. The AnyScan® TRIO three modality design supports all Nuclear Medicine applications with a single CT integration, reducing construction, purchase and maintenance costs. Through high-sensitivity SPECT, diagnostic CT modality and high quality LYSO crystal-based PET, connected with a unified graphical user interface and integrated software solution, this system copes with advanced clinical environment and high-level research fields.

Cechy i zalety

Unique Device Integrating a SPECT/CT and a PET/CT in One System

  • Single-room installation to reduce facility construction, and minimize number of technologists
  • Save on overall servicing, maintenance and spare part costs
  • The common diagnostic CT modality saves the price of a second CT device 
  • Ideal for Nuclear Medicine clinics and private center using dedicated days to schedule conventional NM and PET/CT examinations
  • The system can fit into a PET-CT sized examination room

Seamless Workflow Integration

  • Unified, consistent user interface reducing the learning curve for medical staff and streamlining workflow.   
  • Centralized data management of SPECT, CT, and PET. Images can be stored, accessed, and managed within one system, simplifying data handling and reducing the risk of data loss or mismanagement. 
  • Eliminating the need to switch between different software systems saves time and reduces the complexity of the imaging process.

Ultra-fast SPECT/CT Scanning

  • The third detector and redesigned LEHRHS collimator not even improves image quality, but also saves time for clinicians
  • Optimized continuous workflow by automated reconstruction protocol support
  • Total-Body SPECT/CT scan in 10 - 20 minutes
  • Myocardial examination under 4 minutes

Diagnostic Dual-Performance CT

  • 16 slice diagnostic CT with 32-slice reconstruction
  • Standard Low Dose protocols for diagnostic CT applications
  • Ultra-Low Dose CT with sub-mSv effective dose for attenuation correction and localization
  • Iterative Image Reconstruction with Tera-Tomo™ 3D CT
  • High power CT with up to 440 mA in diagnostic mode, 0.5 sec rotation speed, and 0.625 mm resolution, with on-the-fly dose modulation, Metal Artefact Reduction and Motion Artefact Correction

PET/CT for Routine Oncology Applications

  • Molecular PET imager module with high resolution LYSO detector technology
  • Low-dose patient protocols
  • Time-of-flight PMTs
  • Tera-Tomo™ 3D PET Iterative, real time image reconstruction and 2D FBP reconstruction
  • The high sensitivity and excellent resolution facilitate fast examination process and accurate clinical diagnosis not only for 18F-FDG, but also for 11C-Choline, 11C-MET, 18F-FDOPA, 18F-FET and 68Ga-PSMA

Quantitative Results with Tera-Tomo™ Reconstruction

  • Mediso developed Tera-Tomo™ engine ensures quantitative results with precise SUV values
  • Best image quality and quantitative results
  • GPU based 3D iterative SPECT/CT reconstruction
  • SPECT SUV calculation for radioisotopes. Not only for commonly used tracers like 99mTc, 131I, 123I, 177Lu, but for many more demanding theranostic isotopes
  • Available Normal Databases and possibility to create with easy workflow

Zastosowania

PET/CT in Follow-Up

Follow-up study of a 79-year-old patient suffering from metastatic breast cancer. FDG avid pathological right axillary, mediastinal lymph nodes and multiple bone metastases are visible on 18F-FDG PET/CT scan.

  • Camera: AnyScan® PET/CT system
  • Injected dose: 3.5 MBq/bw kg 18F-FDG
  • Uptake time: 60 min

Sentinel Lymph Node SPECT Imaging in Melanoma

Sentinel lymph node scintigraphy with SPECT/CT in a 46-year-old patient accurately localizes sentinel lymph node(s) and guides surgical removal using gamma probe. Otherwise 18F-FDG PET/CT is essential in melanoma staging at higher Clark level.

SPECT/CT

  • Collimator: LEHR-HS
  • Radiotracer: 99mTc-SentiScint
  • Injected dose: 90 MBq
  • Acquisition: 64 view × 10 sec (320 sec/SPECT)

18F FDG PET/CT in Melanoma Staging

  • Radiotracer: 18F-FDG
  • Injected dose: 5 MBq/bw kg (total: 253.2 MBq)
  • Acquisition: 2 min/FOV (approx. 30 min in total)

Bone SPECT

Bone SPECT images of 68-year-old patient. In the sternum, the right clavicle and the 1st lumbar vertebra, an intense uptake is visible, suggesting metastatic processes.

  • Collimator: LEHR-HS
  • Radiotracer: 99mTc MDP
  • Injected dose: 540 MBq
