Features & Benefits
High sensitivity and high resolution simultaneously
- Proprietary and patented multi-pinhole collimator technology offering excellent spatial resolution, high sensitivity and large field of view at the same time
- Cutting-edge sensitivity even for high-energy isotopes ensured by 9.5 mm thick sodium iodide (NaI:Tl) crystals with large area and minimal detector gaps
- Exclusive imaging performance with ultra-low activity
Absolute quantitative SPECT imaging
- Tera-Tomo™ 3D SPECT reconstruction: iterative SPECT reconstruction engine based on real-time Monte Carlo simulation
- Full range of advanced corrections
- CT- or MRI-based attenuation and scatter correction
- Excellent homogeneity by helical scanning for comparison of regional uptakes
- Time-Activity Curve (TAC) generation and calculation of Standardized Uptake Values (SUV)
Fast dynamic SPECT with Full Stationary imaging
- PET-like dynamic imaging capability with list mode data storage
- Completely motionless acquisition providing time-continuous data from the whole cross-section of the animal
- 3D quantitative dynamic imaging with 1-3 second time frames
- Time-Activity Curve generation from 3D quantitative results.
Largest Field of View for large or multiple animal imaging
- Large detector field of view:
27 cm x 27 cm (10.6” x 10.6”) - Wide gantry opening: up to 27 cm
- Various animal models from tiny mouse to large rabbits (6.5 kg / 14.3 lb)
- Multiple mouse imaging chamber with physiological monitoring feature for all animals
- Wide range of collimation techniques and collimators: Single-Pinhole, Multi-Pinhole and Parallel-hole.
Imaging of Multiple and Theranostic isotopes
- Dedicated multi-pinhole collimators for high-energy imaging
- List-mode data acquisition for simultaneous imaging of multiple isotopes, even for simultaneous scanning of PET and SPECT tracers
- 9.5 mm thick NaI:Tl crystals ensuring high sensitivity for high-energy gamma photons
- Imaging of theranostic isotopes like 131I, 213Bi, 225Ac and more
High power CT with large field of view and high resolution
- Up to 80 W X-ray power enables high-performance scanning even for large or multiple animals
- Variable magnification for high-resolution imaging with 10 μm isotropic voxel size
- Very high throughput: fast scanning with real-time image reconstruction combined with multiple animal imaging capability
- Iterative image reconstruction for low-noise and low-dose imaging
- Ultra-low-dose protocol for follow-up studies with only 1 mSv whole-body dose to the animal
- Imaging with cardiac and respiratory gating
Applications
Publications
Images
Specification
SPECT
CT
MRI
Gantry opening
up to 27 cm
up to 27 cm
Animal models
mouse, rat, marmoset, guinea pig, rabbit (up to 6.5kg), monkey
mouse, rat, marmoset, guinea pig, rabbit (up to 6.5kg), monkey
Multiple animal imaging
up to 3 x 60 g mice
up to 3 x 60 g mice
Detector crystal
9.5 mm NaI(Tl)
9.5 mm NaI(Tl)
Spatial resolution
down to 0.3 mm
down to 0.3 mm
Sensitivity
up to 13 000 cps/MBq
up to 13 000 cps/MBq
Energy range
from 125I to theranostic and PET isotopes
from 125I to theranostic and PET isotopes
Collimators
Wide range of: Multi-pinhole; Single-pinhole; Parallel-hole collimators
Wide range of: Multi-pinhole; Single-pinhole; Parallel-hole collimators
Dynamic imaging
Yes, ultra-fast 4D/5D list mode dynamic imaging by static or rotational SPECT
Yes, ultra-fast 4D/5D list mode dynamic imaging by static or rotational SPECT
Acquisition schemes
SPECT (3D): helical, circular, semi-stationary and full stationaryPlanar (2D): static, dynamic
SPECT (3D): helical, circular, semi-stationary and full stationaryPlanar (2D): static, dynamic
X-ray power
up to 80 W
up to 80 W
Gantry opening
16 cm
16 cm
Transaxial FOV
12 cm
12 cm
Axial FOV
10 cm
10 cm
Animal models
mouse, rat, marmoset, guinea pig, rabbit
mouse, rat, marmoset, guinea pig, rabbit
Multiple animal imaging
up to 3 x 60 g mice
up to 3 x 60 g mice
Image reconstruction
modified Feldkamp-type for real-time reconstruction,iterative reconstruction for low-dose and low-noise applications
modified Feldkamp-type for real-time reconstruction,iterative reconstruction for low-dose and low-noise applications
Spatial resolution
30 μm at 10 μm voxel size
30 μm at 10 μm voxel size
Low-dose protocol
down to 1 mSv for whole-body mouse
down to 1 mSv for whole-body mouse
Magnet
Maintenance-free permanent magnet with 1 Tesla field strength
Maintenance-free permanent magnet with 1 Tesla field strength
Magnetic fringe field
Zero (5 Gauss line is inside the cover)
Zero (5 Gauss line is inside the cover)
Shielding
Integrated RF shielding, no need for Faraday cage
Integrated RF shielding, no need for Faraday cage
RF Coils
Volume coils: whole-body mouse, whole-body rat Surface coils: mouse brain, rat brain
Volume coils: whole-body mouse, whole-body rat Surface coils: mouse brain, rat brain
Spatial resolution
100 μm in vivo<100 µm ex vivo
100 μm in vivo<100 µm ex vivo
